NB-WS2000 High-Precision NB-IOT Wireless Inclinometer Accuracy
0.001° Resolution: 0.0007°
Introduction:
NB-WS2000 is suitable for slope disaster prevention, ancient
building monitoring, dangerous building monitoring, bridge
inclination measurement and other fields. It can meet the needs of
remote real-time monitoring and analysis of physical
characteristics such as uneven settlement and inclined deformation
of structure foundation. Support NB lot and GSM network modes.
Structure data can be uploaded to the cloud through NB IOT or
operator 2G network. Relevant departments can conduct risk
assessment in combination with big data analysis to improve
management efficiency and emergency level and avoid losses.
Performance Index:
| Measurement range(°) | Condition | ±30 |
| Measurement axis | Mutually perpendicular | X-Y |
| Accuracy(°) | Room temperature | 0.001 |
| Resolution(°) | | 0.0007 |
| Zero temperature drift (°/℃) | -40～85℃ | ±0.0007 |
| Cross axis error (°) | 25℃ | 0.001 |
| Automatic sleep mode | Support |
| Timed wake up | Support |
| Exercise wake | Support |
| Mean time between failures MTBF | ≥90000 h |
| Electromagnetic compatibility | According to GBT17626 |
| Insulation resistance | ≥100 MΩ |
| Impact resistance | 2000g,0.5ms,3times/axis |
| Dimension | L109*W65*H72.5 mm |
| Weight | About 500(±10)g |
Application:
● Foundation pit inclinometer
● Tower tilt monitoring
● Dangerous housing monitoring
● Bridge tower inclination measurement
● Ancient building monitoring
BWSENSING's Accuracy Traceability System:
Company introduction
Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast
growing company established in 2010. The company was born in The
Institute of Microelectronics (IME) of Peking University. We have
achieved the top spot in the middle and high-end industry
applications in the Chinese market.
From 2019, BWSENSING ® is approved as our global brand.With 10
years experience in the research-design-development and manufacture
of a range of Inertial sensor technology, BWSENSING posses the
skills, knowledge and experience to provide fully integrated
OEM/ODM design and manufacturing services for Inclinometer,
Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope.
As the company co-founder Dr. Guangyi Shi said, we will use the
Accurate and Cost-effective sensors to make a greater contribution
to the global society for a better IoT world.
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be
traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Commom protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We
accept Paypal/TT/CC.If you purchase in bulk, it is recommended to
consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
