BW-AH500C Series High-Precision Attitude Heading Reference System Inclination accuracy:0.1° with high-quality MEMS
Introduction
BW-AH500C uses high-quality and reliable MEMS devices, and uses
temperature compensation and zero-drift correction algorithms to
ensure measurement accuracy. It has a built-in accelerometer,
gyroscope and magnetometer. It provides reliable heading angle,
roll angle, Pitch angle, angular velocity, acceleration and other
information.
Performance index
| Attitude parameters | Roll, pitch accuracy | 0.1° |
| Heading accuracy | 0.2° |
| Tilt range | Pitch±90º,Roll±180º |
| Gyro | Resolution | 0.01° |
| Range | ±400°/sec |
| Bias stability at full temperature | 5°/h(10s,1σ) |
| Angle random walk | ＜0.1 °/√h |
| Scale factor non-linearity | ≤100ppm(1σ) |
| Scale factor repeatability | ≤100ppm(1σ) |
| Bandwidth | 100Hz |
| Accelerometer | Range: X, Y, Z | ±3.6 g |
| Bias stability | 0.001mg(25℃,100s,1σ) 0.01mg(25℃,10s,1σ) |
| Interface characteristics | Communication mode | RS232/RS485/TTL |
| Maximum output frequency | 200Hz |
Mean time between failures | ≥90000 h/times |
| Electromagnetic compatibility | According to GBT17626 |
| Insulation resistance | ≥100 MΩ |
| Impact resistance | 2000g,0.5ms,3 times/axis |
| Weight(with cable) | 280g |
Application
Robot control
Platform stable
Unmanned aerial vehicle
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be
traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Common protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We
accept Paypal/TT/CC.If you purchase in bulk, it is recommended to
consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
