BW-IMU127C Series Low-Cost Modbus Inertial Measurement Unit RS232
/485/TTL
Introduction
BW-IMU127C uses highly reliable MEMS accelerometers and gyroscopes,
and it uses algorithms to ensure measurement accuracy.
It has a digital interface, which can be easily integrated into the
user's system, and it uses algorithms to ensure measurement
accuracy. At the same time, the sealing design and strict
production process ensure that the product can accurately measure
movement parameters such as the angular velocity, acceleration and
attitude of the carrier in harsh environments.
Performance index
| Gyro | Resolution | 0.01°/sec |
| Range | ±400°/sec |
| Bias stability at room temperature | ＜0.5 °/h(100s,1σ) ＜30 °/h(10s,1σ) |
| Bias stability at full temperature | ＜20 °/h(10s,1σ) |
| Angle random walk coefficient | ＜0.1 °/√h |
| Bias repeatability | ＜50 °/h(1σ) |
| Scale factor non-linearity | ≤100ppm(1σ) |
| Scale factor repeatability | ≤100ppm(1σ) |
| Bandwidth | 100Hz |
| Accelerometer | Range: X, Y, Z | ±3.6 g |
| Resolution | 0.01 mg |
| Bias stability | 0.001mg(25℃,100s,1σ) 0.01mg(25℃,10s,1σ) |
Application
Robots
Stable platform
AGV unmanned vehicle
Construction machinery
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be
traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Common protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We
accept Paypal/TT/CC.If you purchase in bulk, it is recommended to
consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
