    BW-IMU50 Low-Cost Inertial Measurement Unit IMU RS232 /485/TTL Output Optional

    Ask Lasest Price
    Brand Name : BWSENSING
    Model Number : BW-IMU50
    Payment Terms : T/T
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    BW-IMU50 Low-Cost Inertial Measurement Unit IMU RS232 /485/TTL Output Optional

    BW-IMU50 Low Cost Inertial Measurement Unit RS232 /485/TTL Output Optional

    Indroduction

    BW-IMU50 is a low-cost inertial measurement unit that can measure the angular velocity and acceleration of a moving carrier. The data deviation is estimated by the 6-state Kalman filter with appropriate gain, which is suitable for inertial attitude measurement in motion or vibration state.


    Performance index


    GyroResolution0.01°/sec
    Range±400°/sec
    Bias stability at room temperature

    <2°/h(100s,1σ)

    <150°/h(10s,1σ)

    Angle random walk coefficient<0.1 °/√h
    Bias repeatability<50 °/h(1σ)
    Scale factor non-linearity≤100ppm(1σ)
    Scale factor repeatability≤100ppm(1σ)
    Bandwidth100Hz
    AccelerometerRange: X, Y, Z2g
    Resolution0.01mg
    Add zero offset0.15mg
    Bias stability

    0.001mg(25℃,100s,1σ)

    0.01mg(25℃,10s,1σ)



    Application


    Dump truck

    Balance car

    Stable platform

    AGV unmanned guided vehicle


    FAQ


    Q1: Accuracy definition of products

    A: RMS accuracy, the accuracy of each product can be traced.Accuracy test report can be provided if required.


    Q2: How to select suitable model?

    A: Users should check the following points:

    a. Single or dual axis?

    b. Commom protocol, Modbus or CAN?

    c. Dynamic or static Application scenarios?

    d. Horizontal or vertical installation?


    Q3: How to purchase?

    A: If you want sample, please purchase on BWSENSING online shop. We accept Paypal/TT/CC.If you purchase in bulk, it is recommended to consult the sales for the best price.


    Q4: How long is the warranty period?

    A: One year.


    Company introduction

    Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast growing company established in 2010. The company was born in The Institute of Microelectronics (IME) of Peking University. We have achieved the top spot in the middle and high-end industry applications in the Chinese market.

    From 2019, BWSENSING ® is approved as our global brand.With 10 years experience in the research-design-development and manufacture of a range of Inertial sensor technology, BWSENSING posses the skills, knowledge and experience to provide fully integrated OEM/ODM design and manufacturing services for Inclinometer, Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope. As the company co-founder Dr. Guangyi Shi said, we will use the Accurate and Cost-effective sensors to make a greater contribution to the global society for a better IoT world.
