BW-AH100 Series Low-cost Attitude Heading Reference System Pitch
accuracy 3°(RMS, dynamic) 0.5°(RMS, static)
Introduction
The BW-AH100 heading and attitude reference system product is a
low-cost inertial measurement device.
It uses industrial-grade MEMS accelerometers, gyroscopes and
magnetometers, and uses algorithms to ensure measurement accuracy.
BW-AH100 has a digital interface, which can be easily integrated
into the user's system.
Performance index
Attitude parameters | Pitch accuracy | 3°(RMS, dynamic) 0.5°(RMS, static) |
| Roll accuracy | 3°(RMS, dynamic) 0.5°(RMS, static) |
| Resolution | 0.01° |
| Tilt range | Pitch± 90º,Roll±180º |
| Heading parameters | Heading accuracy | 2° |
| Resolution | 0.01° |
Physical characteristics | Dimension | L55 x W37 x H24(mm) |
| Weight (with cable) | 60g |
| Output mode | RS232/RS485/TTL |
Interface characteristics | Start-up delay | <3s |
| Maximum output frequency | 100Hz |
| Serial communication rate | 2400 to115200 Baud rate |
Digital output format | Binary high-performance protocol |
| Environment | Impact resistance | 2000g |
Application
Drilling equipment measurement and control
Ocean Surveyor
Robot control
Aerial work truck
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be
traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Common protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We
accept Paypal/TT/CC.If you purchase in bulk, it is recommended to
consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
