    BW-AH100C Low-Cost Attitude And Heading Reference AHRS RS232/RS485/TTL

    BW-AH100C Series Low-cost Attitude Heading Reference System Tilt range Pitch±90º, Roll±180º ARW <0.1 °/√h


    Introduction

    BW-AH100C has a digital interface, which can be easily integrated into the user's system.Through various compensations such as nonlinear compensation, quadrature compensation, temperature compensation and drift compensation, the error source of BW-AH100C can be greatly eliminated and the product accuracy level can be improved.


    Performance index



    Attitude parameter


    Roll/Pitch accuracy
    Heading accuracy
    Tilt rangePitch±90º,Roll±180º
    GyroResolution0.01°
    Range±400°/sec
    Bias stability at full temperature30 °/h(10s,1σ)
    ARW<0.1 °/√h
    Scale factor non-linearity≤100ppm(1σ)
    Scale factor repeatability≤100ppm(1σ)
    Bandwidth100Hz
    AccelerometerRange: X, Y, Z±3.6 g
    Bias stability

    0.001mg(25℃,100s,1σ)

    0.01mg(25℃,10s,1σ)

    Interface characteristicsCommunication modeRS232/RS485/TTL
    Maximum output frequency100Hz

    MTBF

    ≥90000 h/time
    EMCAccording to GBT17626
    Insulation resistance≥100 MΩ
    Impact resistance2000g,0.5ms,3 times/axis
    Weight(with cable)280g


    Application

    Satellite tracking

    Ocean Surveyor

    ROV underwater robot navigation

    Robot control


    FAQ

    Q1: Accuracy definition of products

    A: RMS accuracy, the accuracy of each product can be traced.Accuracy test report can be provided if required.


    Q2: How to select suitable model?

    A: Users should check the following points:

    a. Single or dual axis?

    b. Common protocol, Modbus or CAN?

    c. Dynamic or static Application scenarios?

    d. Horizontal or vertical installation?


    Q3: How to purchase?


    A: If you want sample, please purchase on BWSENSING online shop. We accept Paypal/TT/CC.If you purchase in bulk, it is recommended to consult the sales for the best price.


    Q4: How long is the warranty period?

    A: One year.


    Company introduction

    Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast growing company established in 2010. The company was born in The Institute of Microelectronics (IME) of Peking University. We have achieved the top spot in the middle and high-end industry applications in the Chinese market.

    From 2019, BWSENSING ® is approved as our global brand.With 10 years experience in the research-design-development and manufacture of a range of Inertial sensor technology, BWSENSING posses the skills, knowledge and experience to provide fully integrated OEM/ODM design and manufacturing services for Inclinometer, Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope. As the company co-founder Dr. Guangyi Shi said, we will use the Accurate and Cost-effective sensors to make a greater contribution to the global society for a better IoT world.
