    BWM426 Cost-Effective Digital Dual-Axis Inclinometer Tiltmeter RS232/RS485/TTL Optional

    Ask Lasest Price
    Brand Name : BWSENSING
    Model Number : BWM426
    Payment Terms : T/T
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    BWM426 Cost-Effective Digital Dual-Axis Inclinometer Tiltmeter RS232/RS485/TTL Optional

    BWM426 Cost-Effective Digital Dual-Axis Inclinometer Tiltmeter RS232/RS485/TTL Optional


    Introduction:


    BWM426 MEMS dual-axis inclination sensor is suitable for equipment automation, industrial leveling, solar automatic tracking and other industries. The resolution is 0.001 °, the maximum accuracy is 0.01 °, and the working temperature is - 40 ℃ - + 85 ℃. The horizontal inclination value is directly output through digital mode, and the built-in automatic compensation and filtering algorithm can effectively eliminate the error caused by environmental change.


    Performance Index:


    Measurement Range (°)

    Condition±90
    Measurement axisX-Y
    Accuracy (°)Room temperature0.01
    Resolution (°)Completely still0.001
    Zero bias (°/℃)-40~85℃±0.005
    Start-up time<3s
    Output frequency (Hz)5-100Hz adjustableUp to 100
    Mean time between failures MTBF≥90000h
    Electromagnetic compatibilityAccording to GBT17626
    Insulation resistance≥100 MΩ
    Impact resistance2000g,0.5ms,3 times/axis


    Application:


    ● Structural deformation monitoring

    ● Surveying and Mapping Instruments

    ● Equipment automation

    ● Lifting equipment inclination control

    ● Industrial automatic leveling

    ● Medical instruments


    BWSENSING's Accuracy Traceability System:


    BWM426 Cost-Effective Digital Dual-Axis Inclinometer Tiltmeter RS232/RS485/TTL Optional


    Company introduction

    Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast growing company established in 2010. The company was born in The Institute of Microelectronics (IME) of Peking University. We have achieved the top spot in the middle and high-end industry applications in the Chinese market.

    From 2019, BWSENSING ® is approved as our global brand.With 10 years experience in the research-design-development and manufacture of a range of Inertial sensor technology, BWSENSING posses the skills, knowledge and experience to provide fully integrated OEM/ODM design and manufacturing services for Inclinometer, Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope. As the company co-founder Dr. Guangyi Shi said, we will use the Accurate and Cost-effective sensors to make a greater contribution to the global society for a better IoT world.



    FAQ


    Q1: Accuracy definition of products

    A: RMS accuracy, the accuracy of each product can be traced.Accuracy test report can be provided if required.


    Q2: How to select suitable model?

    A: Users should check the following points:

    a. Single or dual axis?

    b. Commom protocol, Modbus or CAN?

    c. Dynamic or static Application scenarios?

    d. Horizontal or vertical installation?


    Q3: How to purchase?

    A: If you want sample, please purchase on BWSENSING online shop. We accept Paypal/TT/CC.If you purchase in bulk, it is recommended to consult the sales for the best price.


    Q4: How long is the warranty period?

    A: One year.
