VG50 Low-cost Digital Dynamic Inclinometer RS232/485/TTL/CAN
Optional Dynamic And Static Measurement
Introduction:
Vg50 is a low-cost attitude measurement equipment, which is
suitable for inertial attitude parameter measurement of moving
carrier. It adopts MEMS accelerometer and gyroscope with high quality and
reliability.High-performance Kalman filter algorithm is built in it
to ensure accuracy.Through nonlinear compensation, quadrature
compensation, temperature compensation and drift compensation, the
error caused by interference can be greatly eliminated.
Performance Index:
Attitude Parameter | Dynamic accuracy | 3° |
| Static accuracy | 0.3° |
| Resolution | 0.01° |
| Tilt margin | Pitch±90º,Role±180º |
Physical properties | Dimension | L55 x W37 x H24(mm) |
| Weight (with wire) | 130g |
| Weight (With packaging) | 210g |
Interface characteristics | Start delay | <50ms |
| Maximum sampling rate frequency | 100Hz |
| Serial communication rate | 2400 to115200 bps
|
| Digital output format | Binary high-performance protocol |
| Trouble-free work on average | ≥90000 hours |
| EMC | According to GBT17626 |
| Insulation Resistance | ≥100 MΩ |
| Surge suppression | 2000g,0.5ms,3 Time/shaft |
Application:
● Marine vessels
● Construction Machinery
● Platform stability
● Agricultural machinery
● ROV underwater robot navigation
● Unmanned Drive
● Robot
● Unmanned Craft
BWSENSING's Accuracy Traceability System:
Company introduction
Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast
growing company established in 2010. The company was born in The
Institute of Microelectronics (IME) of Peking University. We have
achieved the top spot in the middle and high-end industry
applications in the Chinese market.
From 2019, BWSENSING ® is approved as our global brand.With 10
years experience in the research-design-development and manufacture
of a range of Inertial sensor technology, BWSENSING posses the
skills, knowledge and experience to provide fully integrated
OEM/ODM design and manufacturing services for Inclinometer,
Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope.
As the company co-founder Dr. Guangyi Shi said, we will use the
Accurate and Cost-effective sensors to make a greater contribution
to the global society for a better IoT world.
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be
traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Commom protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We
accept Paypal/TT/CC.If you purchase in bulk, it is recommended to
consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
