BWL315S Small-Size Cost-Effective CAN Bus Single Axis Inclinometer
Introduction:
BWL315S is applicable to industries such as industrial automatic
leveling, medical equipment, tower tilt monitoring, etc. This
product converts the change of static gravity field into the change
of inclination angle, and directly outputs the value of horizontal
inclination angle through voltage. It has the advantages of low
cost, small temperature drift, simple use and strong
anti-interference ability.
Performance Index:
Measurement Range (°) | Condition | ±180 |
| Measurement axis | | X |
| Accuracy (°) | Room temperature | 0.2 |
| Resolution (°) | Completely still | 0.01 |
| Zero bias (°/℃) | -40~85℃ | ±0.02 |
| Start-up time | | ＜3s |
| Output frequency (Hz) | 5-100Hz adjustable | Up to 100 |
| Mean time between failures MTBF | ≥90000 h/times |
| Electromagnetic compatibility | According to GBT17626 |
| Insulation resistance | ≥100 MΩ |
| Impact resistance | 2000g,0.5ms,3 times/axis |
| Weight (g) | 210(without outer packaging) |
Application:
● Industrial automatic leveling
● Medical instruments
● Photovoltaic automatic tracking
● Special valve
● Oil drilling equipment
BWSENSING's Accuracy Traceability System:
Company introduction
Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast
growing company established in 2010. The company was born in The
Institute of Microelectronics (IME) of Peking University. We have
achieved the top spot in the middle and high-end industry
applications in the Chinese market.
From 2019, BWSENSING ® is approved as our global brand.With 10
years experience in the research-design-development and manufacture
of a range of Inertial sensor technology, BWSENSING posses the
skills, knowledge and experience to provide fully integrated
OEM/ODM design and manufacturing services for Inclinometer,
Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope.
As the company co-founder Dr. Guangyi Shi said, we will use the
Accurate and Cost-effective sensors to make a greater contribution
to the global society for a better IoT world.
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be
traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Commom protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We
accept Paypal/TT/CC.If you purchase in bulk, it is recommended to
consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
Q5: Can analog quantity change the range?
A: User-defined settings can be made on the Beiwei host computer
with RS232-USB through the reserved RS232 wire harness.
