BWK216S Low-Cost Digital Single Axis Inclinometer Photovoltaic
Power Generation RS232/RS485/TTL Optional
Introduction:
BWK216s is a low-cost and small volume uniaxial inclination sensor
with digital output. It directly outputs the horizontal inclination
value by converting the change of static gravity field into
inclination change. It has the characteristics of simple use, small
temperature drift and strong anti-interference ability. It is the
best choice for inclination measurement in tower monitoring,
photovoltaic power generation, PTZ control and other industries.
Performance Index:
Measurement Range (°) | Condition | ±180 |
| Measurement axis | | X |
| Accuracy(°) | Room temperature | 0.2 |
| Resolution(°) | Completely still | 0.02 |
| Zero bias (°/℃) | -40〜85℃ | ±0.02 |
| Start-up time | | ＜3s |
| Output frequency (Hz) | 5-100Hz adjustable | Up to 100 |
| Mean time between failures MTBF | ≥90000 h |
| Electromagnetic compatibility | According to GBT17626 |
| Insulation resistance | ≥100 MΩ |
| Impact resistance | 2000g,0.5ms,3times/ axis |
| Weight (g) | 210( Without outer packaging ) |
Application:
● Industrial automatic leveling
● Medical instruments
● Photovoltaic automatic tracking
● Oil drilling equipment
● Industrial converter
BWSENSING's Accuracy Traceability System:
Company introduction
Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast
growing company established in 2010. The company was born in The
Institute of Microelectronics (IME) of Peking University. We have
achieved the top spot in the middle and high-end industry
applications in the Chinese market.
From 2019, BWSENSING ® is approved as our global brand.With 10
years experience in the research-design-development and manufacture
of a range of Inertial sensor technology, BWSENSING posses the
skills, knowledge and experience to provide fully integrated
OEM/ODM design and manufacturing services for Inclinometer,
Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope.
As the company co-founder Dr. Guangyi Shi said, we will use the
Accurate and Cost-effective sensors to make a greater contribution
to the global society for a better IoT world.
FAQ
Q1: Accuracy definition of products
A: RMS accuracy, the accuracy of each product can be
traced.Accuracy test report can be provided if required.
Q2: How to select suitable model?
A: Users should check the following points:
a. Single or dual axis?
b. Commom protocol, Modbus or CAN?
c. Dynamic or static Application scenarios?
d. Horizontal or vertical installation?
Q3: How to purchase?
A: If you want sample, please purchase on BWSENSING online shop. We
accept Paypal/TT/CC.If you purchase in bulk, it is recommended to
consult the sales for the best price.
Q4: How long is the warranty period?
A: One year.
